Feature:

1. MPPT solar charge controller built-in

2. Touch color screen, intelligent control, easy operation

3. Innovative operation system.All the operation adjustment can be done on the touch screen easily.Can see daily data,monthly data and total data on the screen.

4. WIFI is optional.can control the inverter remotely and check the running data

5. Lithium battery,gel battery,lead-acid battery are all acceptable.One touch can switch battery type!Just tell our sales the battery type when confirm order is OK.

6. Conformal coating is sprayed on the surface of the PCB,provide perfect protection to the inverter. low voltage protection, high voltage protection, over temperature protection, short-circuit protection, overload protection, alarm alert.

7.Big MOSFET,Big capacitor and Big heat sink. The inverter has bigger load carrying ability and higher load capacity, this series of inverter can drive not only common resistance loads,but also various kinds of inductive loads, such as air conditioner, electric drills, motors,water pump,etc.

8. Low frequency transformer based design with stable quality, low failure rate and long service life (under proper operation, it can last at least 8 years)

Solar Panel Inverter

SOLAR INVERTER SERIES-PRODUCT OVERVIEW

MHIC series with dual MCU design, PV charge controller and inverter integrated optimization solutions, to provide users with the best experience. Pure sine wave output to meet various types of load; mains supply preferred mode / power saving mode /battery preferred mode for easy meeting of the needs of different users. Using intelligent optimization SOC control, a separate three-stage solar charge management, improve the effectiveness of the charging of the battery.LCD display integrated inverter and photovoltaic panels, equipment operating status intuitive, concise manipulation.It is widely applied to families, schools, streets, border,pastoral, industrial equipment, satellite communications equipment, ships and so on.

Model: MPPT		10kw
power rating(w)		8000
Battery	rated voltage(VDC)	48
	AC Charge Current	30A MAX
	Battery Type	Can be set
Input	Voltage Range	170-275VAC
Input	frequency	45-65Hz
Output	Voltage Range	220VAC-240VAC; ±5%( Inverter mode)
	frequency	50/60Hz±1%( Inverter mode)
	Output wave	Pure Sine Wave
	Change time	＜10ms(Typical load)
	Efficiency	＞85%（80% Resistive load）
	overload	110-120%/30S；＞160%/300ms；
	Protection function	Battery over-voltage and low-voltage protection, overload protection, short circuit protection, over-temperature protection
Solar Controller	MPPT Voltage Range	72V~150VDC
	PV Power	120A(7200W)
	Rated charge current	120A(Max)
	MPPT efficiency	≥99%
	Average charging voltage(lead acid battery	56.8VDC
	Floating charge voltage	55VDC
Operating ambient temperature		-15-+60℃
Storage ambient temperature		-20 - +60℃
Operating / storage environment		0-90% No Condensation
Dimensions:W * D * H (mm)		730490240

Company profile

Sunchees was founded in 2008, head office and factory is located in Foshan, Guangdong. China,but its sales network has spread to more than 100 countries and regions around the world.

solor power panel self install

Main business: solar power system one stop solutions, solar inverter , solar air conditioner system, solar street light system . solar DC power system ect .

complete solar system for home

Sunchees products are widely used in home, agriculture, industry, finance, electric power, transportation, security, new energy. Its stable and excellent performance have been widely recognized.

lithium battery for solar system
